To better learn about cnc service, Euromicron will provide detailed pictures and detailed information in the following section for your reference.The products we produce are in strict line with the . Their high quality is guaranteed through reliable material sourcing and strict QC methods.Euromicron is certified by various qualifications. We have advanced production technology and great production capability. cnc service has many advantages such as reasonable structure, excellent performance, good quality, and affordable price.

Company Advantages
1. Euromicron Mould electronica injection moulding is manufactured with qualified raw materials that are sourced from reliable suppliers.
2. This product has no electrical safety problem. A built-in protection system on the board helps avoid electric leakage.
3. Before our loading for electronic parts , we will hold a comprehensive checking again to ensure quality.

Part Name:	Electronic connector
Part size:	18153mm
Raw Material:	NYLON+30%GF
Color:	RAL9005,Black
Mould Cavity No.:	16+16
Injection gate:	Cold runner
Surface finished:	Polishing #600
Core &Cavity steel:	1.2344, hardness 48~52HRC
Mold component standard:	DME or equivalent
Injection machine size:	120T
Cycle time:	18S
Mold life:	300000 shots
Customer:	AEC
Export:	USA

◇◆ Summary for project running

This product used for electrical connector. And was supposed to be molded in glass-fiber-reinforced, flame-retardant nylon.

There are many small pin holes on part. Hole’s diameter is 0.6mm with 2.2mm distance of each. Dimension tolerance should be within +/-0.01mm. Mold design-We will make this mold with 2+2cavity, cold runner in to banana gate. To make parts leave on core side, parting line should be on top. And all pin holes location need to be inserted. Because the hole diameter and distance need to keep in strict tolerance. Separated insert make it easy to replace. Need to pay high attention to electrode making and EDM process. We made whole electrode include all pin holes position, then checked by CMM machine, until shown it was made in proper dimension, took to Mirror EDM manufacture.

Injection-Any mismatch or flash in switch(female half) hole would cause male half pin bend, so this request holding pressure not too high. but also guarantee not cause sink mark on outside surface. Although the part and mold is small, enough cooling line still necessary. Because the part quantity in demand is one million each month, we need to cut down cycle time as much as possible. So that we can save production cost.
