Euromicron Mould electronics plastic enclosure box wholesale for andon electronics

Euromicron Mould electronics plastic enclosure box wholesale for andon electronics
  • Euromicron Mould electronics plastic enclosure box wholesale for andon electronics
  • Euromicron Mould electronics plastic enclosure box wholesale for andon electronics
  • Euromicron Mould electronics plastic enclosure box wholesale for andon electronics

Euromicron Mould electronics plastic enclosure box wholesale for andon electronics

Our skilled professionals supervise the quality control throughout the production, greatly guaranteeing the quality of the product.
Inquire Online
Get the latest price
Quantity Needed:
Pieces
E-mail:
Enterprise Strength
  • Our excellence comes from the efforts of staff from such departments as R&D department, sales department, design department and production department. There are designers, R&D experts, and after-sales personnel in our company.
  • Euromicron can provide professional and practical services based on customer demand.
  • Euromicron always sticks to our tenet of "quality comes first" by focusing on the quality control, service improvement, and fast response.
  • We have been dedicated to the manufacturing of cnc service for about years, and have become the leading enterprise in the industry. This enables us to introduce and operate a complete set of production equipment, and achieve intelligentization and standardization.
  • Since the establishment, our sales network has been continuously expanding to where our sales service is highly appraised by customers at home and abroad. In future, we would like to establish our marketing network overseas and expand the business further.
Company Advantages
1. Euromicron Mould plastic enclosure box stands out under the sophisticated production process.
2. Our skilled professionals supervise the quality control throughout the production, greatly guaranteeing the quality of the product.
3. Each staff of Euromicron Mould has been skilled in plastic enclosure box industry for years.


Part Name:Electronic connector
Part size:18*15*3mm
Raw Material:NYLON+30%GF
Color:RAL9005,Black
Mould Cavity No.:16+16
Injection gate:Cold runner
Surface finished: Polishing #600
Core &Cavity steel:1.2344, hardness 48~52HRC
Mold component standard:DME or equivalent
Injection machine size:120T
Cycle time:18S
Mold life:300000 shots
Customer:AEC
Export:USA


◇◆ Summary for project running
This product used for electrical connector. And was supposed to be molded in glass-fiber-reinforced, flame-retardant nylon.
Euromicron Mould electronics plastic enclosure box wholesale for andon electronics-1

There are many small pin holes on part. Hole’s diameter is 0.6mm with 2.2mm distance of each. Dimension tolerance should be within +/-0.01mm.   Mold design-We will make this mold with 2+2cavity, cold runner in to banana gate. To make parts leave on core side, parting line should be on top. And all pin holes location need to be inserted. Because the hole diameter and distance need to keep in strict tolerance. Separated insert make it easy to replace. Need to pay high attention to electrode making and EDM process. We made whole electrode include all pin holes position, then checked by CMM machine, until shown it was made in proper dimension, took to Mirror EDM manufacture.

Euromicron Mould electronics plastic enclosure box wholesale for andon electronics-2

Injection-Any mismatch or flash in switch(female half) hole would cause male half pin bend, so this request holding pressure not too high. but also guarantee not cause sink mark on outside surface. Although the part and mold is small, enough cooling line still necessary. Because the part quantity in demand is one million each month, we need to cut down cycle time as much as possible. So that we can save production cost.




Company Features
1. Euromicron Mould Engineering Limited is one of the major firms offering plastic enclosure for electronic products in China. We are known for having unrivaled experience in quality product manufacturing.
2. Quality is above everything in Euromicron Mould Engineering Limited.
3. We seek to be agents of change – for our clients, our partners, our people, and society. We are committed to creating a competitive advantage to our clients through unique custom solutions. We favor the concept of reducing carbon footprint during production. Attaching high importance to the wastes such as water and gases, we will not discharge these wastes illegally or randomly, instead, we may collect some of the wastes and utilize it for different purposes. Inquire now! In order for our company to be socially responsible, we implement environmental sustainability plans. For example, we do recycling work, waste management, greener supply chains, reducing water source waste, etc. Inquire now! The absolute goal of our environmental work is that our industrial processes should have the lowest possible impact on the environment. Our strategy is to stay one step ahead of official requirements by implementing an active environmental management system and to continuously improve our environmental standard. Inquire now!
The design of Euromicron Mould plastic enclosure for electronic products fuses traditional and contemporary elements. It is carried out by designers who have developed an inherent sensitivity towards the materials and classical architectural elements that are condensed in modern decorative arts. This product has the advantage of excellent breathability
The necessary tests for Euromicron Mould plastic enclosure for electronic products have been conducted. These tests include flexibility testing, dimension stability testing, slip resistance testing, and fatigue resistance testing. This product simply requires a short charging time
The design of Euromicron Mould plastic enclosure box is an unrivaled blend of creativity, innovation and market potential. It, carried out by professional designers who deliver a collection of contemporary design furnishing, embraces unconventional color mix ideas and shape design know-how. Built-in a temperature controller, this product can achieve optimal heated comfort
The design of Euromicron Mould plastic enclosure for electronic products is an integration of some necessary elements. They are color matching, texture, lines, pattern silhouette, shape, etc. This product is the perfect blend of fashion and utility
A wide variety of manufacturing processes of Euromicron Mould plastic enclosure for electronic products are as followed: pattern design, fabric sourcing, fabric pre-treatment, grading, layout, cutting, sewing, and ironing. This product is available in various sizes
We adhere to strict quality industry standards and fully guarantee that our products meet international standards. Its exterior shell is made of insulation materials, which can guarantee the maximum warmth
