high productivity electronic housing andon manufacturer for andon electronics

Company Advantages
1. Advanced production technology: electronic housing is manufactured following the guidance of lean production method and completed by the combined efforts of advanced equipment and skilled workers. Its structure proves to be firm and stable
2. Euromicron Mould Engineering Limited relys on the great power of its funds and technology to enable electronic housing R&D and manufacturing up to the international advanced standard. The product can be applied in many industries, such as the automobile, house appliance, and medical industry
3. Its quality is guaranteed by a team of people following the relative certificates. The product stands out with its excellent dimensional consistency
4. With the quality certification, the product is of higher performance than other products. Vacuum packing method is adopted for the product to avoid mold rusting during transportation

Part Name:	Electronic connector
Part size:	18153mm
Raw Material:	NYLON+30%GF
Color:	RAL9005,Black
Mould Cavity No.:	16+16
Injection gate:	Cold runner
Surface finished:	Polishing #600
Core &Cavity steel:	1.2344, hardness 48~52HRC
Mold component standard:	DME or equivalent
Injection machine size:	120T
Cycle time:	18S
Mold life:	300000 shots
Customer:	AEC
Export:	USA

◇◆ Summary for project running

This product used for electrical connector. And was supposed to be molded in glass-fiber-reinforced, flame-retardant nylon.

Euromicron Mould andon electronic housing manufacturer for andon electronics-1

There are many small pin holes on part. Hole’s diameter is 0.6mm with 2.2mm distance of each. Dimension tolerance should be within +/-0.01mm. Mold design-We will make this mold with 2+2cavity, cold runner in to banana gate. To make parts leave on core side, parting line should be on top. And all pin holes location need to be inserted. Because the hole diameter and distance need to keep in strict tolerance. Separated insert make it easy to replace. Need to pay high attention to electrode making and EDM process. We made whole electrode include all pin holes position, then checked by CMM machine, until shown it was made in proper dimension, took to Mirror EDM manufacture.

Euromicron Mould andon electronic housing manufacturer for andon electronics-2

Injection-Any mismatch or flash in switch(female half) hole would cause male half pin bend, so this request holding pressure not too high. but also guarantee not cause sink mark on outside surface. Although the part and mold is small, enough cooling line still necessary. Because the part quantity in demand is one million each month, we need to cut down cycle time as much as possible. So that we can save production cost.
