Euromicron Mould accessories auto parts mould renovation solutions for businessman

Euromicron Mould Engineering Limited is renowned for excellence in developing and manufacturing injection molding automotive . We have gained market recognization.
Inquire Online
Get the latest price
Quantity Needed:
Pieces
E-mail:
Application Scope
Euromicron's die casting mold has a wide range of applications.Euromicron is committed to providing customers with high-quality cnc service as well as one-stop, comprehensive and efficient solutions.The products we produce are in strict line with the . Their high quality is guaranteed through reliable material sourcing and strict QC methods.
Company Advantages
1. Materials such as injection molding automotive guarantee the service life of auto parts mould .
2. The product is regularly reviewed for quality to ensure reliable quality.
3. Euromicron Mould has enough ability to produce qualified auto parts mould with high quality.
4. With stable quality, auto parts mould can customize according to customer requirements.


Euromicron Mould accessories auto parts mould renovation solutions for businessman-1
Euromicron Mould accessories auto parts mould renovation solutions for businessman-2



◇◆ Mold introduce


Euromicron Mould accessories auto parts mould renovation solutions for businessman-3

This is a loudspeaker cover, which is used in QianTu car. The material is PC+ABS. The size of the part is 217*206*30mm. There are many small holes and thin ribs on the part. There are two stamps with month and years. The marks are recycle and name of plastic material. And five hooks are used to fix on the frame of loudspeaker. The finish is grain (VDI 3400 ref 30) on viewable surface and polished on the inner surface. No flash、injection gate、ejector mark and fault are allowed on the viewable surface. To produce the part, it need a injection mold with good venting and good finish.

Euromicron Mould accessories auto parts mould renovation solutions for businessman-4

A mold with one cavity and hot runner system was built to produce the part. Five angular lifters were designed to form the hooks. The mold was cooled by cooling water. The cycle time was about 39 seconds. The part was ejector out by round ejecting pins. For the mold, the most important was to manufacture the area with small holes and the thin ribs. Core insert can't be milled by CNC and polished because there were too compact small holes and thin ribs.

Euromicron Mould accessories auto parts mould renovation solutions for businessman-5

So it needed to make graphite electrode to do EDM. The finish of the surface is 4u-6u Rmax.In this way, the part can demould smoothly without polished. To get good surface of the electorde, it was very import to choice the graphite grade. The graphite must be high strength and fine particles. The size of the particles was about 1-5μm. Too many holes had an effect on flowing of the plastic material when injecting. It was easy to cause venting issue.

Euromicron Mould accessories auto parts mould renovation solutions for businessman-6

So it needed a good venting system in the mold. So that some venting inserts were designed in the core side of the mold. To get the viewable surface with EDM texture VDI 3400 ref30, a big copper electrode was made to do EDM. It was a high precision electrode. Also it was done in a good EDM machine. To make lifters moving smoothly, the holes of the lifters were made by slow wire cutting. And a copper guide block was designed for the lifter.



Company Features
1. Euromicron Mould Engineering Limited is renowned for excellence in developing and manufacturing injection molding automotive . We have gained market recognization.
2. The factory is manned with a powerful R&D (Research & Development) team. It is this team that provides a platform for product creativity and innovation and helps our business grow and flourish.
3. With sticking to the idea of striving for perfection, Euromicron Mould will continually create more values for our customers. Inquire! To guarantee high quality of auto parts mould is our promise. Inquire!
Euromicron Mould auto parts mould is designed and manufactured at par the market prevalent norms. The product has a good bearing capacity which is shock-resistant
The design of auto parts mould is very innovative following the latest design trends in the industry.It is made of environmentally-friendly materials to protect the ecological system
The production level of Euromicron Mould injection molding automotive is up to the international standards. It can be freely combined with other products to maximize the space
The product manufactured by Euromicron Mould is very popular among customers. It is highly evaluated by customers around the world, such as the Middle East, Africa, and Southeast Asia
Strong R&D capability: Euromicron Mould injection molding automotive is carefully developed by a team of dedicated professionals. In addition to that, a lot of money has been invested to improve the R&D strength. The material of the product can be recycled
This product is tested before delivery to meet top-notch quality standards. It is frequently displayed in the international exhibition, such as the Canton Fair
