custom plastic enclosures electronics product for electronic components Euromicron Mould

custom plastic enclosures electronics product for electronic components Euromicron Mould

Part Name
Gateway
Part size
175*136*32mm
Raw Material
ABS+PC
Color
RAL9010,Whit
Mould Cavity No
1*1
Injection gate
Hot runner with pin point gate
Surface finished
Mirror Polishing
Product Comparison
Closely following the market trend, Euromicron uses advanced production equipment and manufacturing technology to produce injection mold. The product receives favors from the majority of customers for the high quality and favorable price.The products we produce are in strict line with the . Their high quality is guaranteed through reliable material sourcing and strict QC methods.Euromicron's injection mold has been further improved based on advanced technology, as reflected in the following aspects.
Application Scope
Euromicron's injection mold is widely used and can be applied to all walks of life.With many years of practical experience, Euromicron is capable of providing comprehensive and efficient one-stop solutions.The products we produce are in strict line with the . Their high quality is guaranteed through reliable material sourcing and strict QC methods.
Company Advantages
1. Our electronic parts enjoys a longer lifespan than other similar products for its custom plastic enclosures electronics material.
2. The product is not likely to form bacteria on its surfaces. Its coated surface greatly reduces the number of bacteria that is able to grow on the surface.
3. Due to these features, it has been widely used in many applications.


Part Name:Gateway
Part size:175*136*32mm
Raw Material:ABS+PC
Color:RAL9010,White
Mould Cavity No.:1*1
Injection gate:Hot runner with pin point gate
Surface finished: Mirror Polishing
Core &Cavity steel:1.2344,hardness 48~52HRC
Mold component standard:HASCO or equivalent
Injection machine size:180T
Cycle time:35S
Mold life:300000 shots
Customer:HEKATR@N
Export:Germany


◇◆ Summary for project running
This product used for electrical appliance,the gateway case and grid.Plastic raw material need in inflaming retarding and heat resistant.

We carried out first trial shot on 40th day,little longer than planed.Since YUDO hot runner system came out of expected date,one week late.Three trial shots for samples production,and finished whole project in 50days.Manufacture schedule,samples delivery and mold shipment date ran as planing,within customer’s request.
Both parts critical surface need in high polishing,mirror grade,no any marked or scratch allowed.When production,have to take out by robot hand,and cover PE film for protection. Silkscreen also made by EMM factory.

At first trial shot,case part came out with obvious sink mark and scratch on side surface. The ribs inside are too thick cause sink mark,and no draft angle on side surface cause scratch when mold open.Finally We cut rib material solved sink mark problem.But no draft angle allowed on side surface,we had to add two sliders on both side,to ensure all outside surface look glossy.
The grid part has many small window and only 0.6mm thick.We found flowing mark at each window corner and short shot problem at first trial shot.Then we suggested change high polishing surface to fine texture,VDI3400-33,also change injection gate location,from both side for filling.Customer confirmed and part came out look good.




Company Features
1. Euromicron Mould Engineering Limited is one of the large companies in the industry of electronic parts , which has outstanding and competitive advantages.
2. Our quality is our company name card in communication processor industry, so we will do it best.
3. The spirit of custom plastic enclosures electronics has been formed in the course of more than decades of years of Euromicron Mould Engineering Limited development. Get price! Euromicron Mould always believes that the friendly communication relationship helps both sides in different ways. Get price!



Parts:



LCD+touch Digitizer+frame



Screen size:



4.0 inch



Resolution:



1136x640P



Material:



Retina



Color:



Black/Whtie

Sample Policy:

Sample available

Quality Control:

1)100% brand new;

2)2 Function+1 Cosmetic Test

Warranty:

18 months

Delivery time:

Within 1-3days

After-sales (Return policy):

We will exchange new one for free if there is any defects, after you get the part.

Shipment Items:

1)Goods will be delivered by DHL, UPS, FedEx, EMS, TNT, HKEMS methods
2)Large order by sea or by air.











Product Description



 ColorBlack
 Quality 100% Original/ Grade AAA/ JDF/ SC/ TIANMA/ LT/ YD.
 LCD Assembly LCD digitizer + Front Glass + Touch Screen + Frame
 Warranty 12 Months
 Package Bubble bag + PVC plasitc box + Foam box
 Inspection 100% Double Check before Shipping
 Delivery time 1-3 Working Days after Payment
 Payment  T/T, Western Union, MoneyGram, Visa, Master, E-checking,etc...
 Shipment DHL, UPS, FedEx, EMS etc
 Advantages

 1.Factory directly supply to customer since 2000.

 2.Better service with best quality.

 3.12 months warranty.
